Two female and one male connector allow easy connected to Garmin NMEA 2000 Lite cable assemblies even when field fit connectors are used, making it a totally unique T-piece.
The Garmin NMEA 2000 T piece is for use where a drop or 'port' is required from the NMEA 2000 backbone to connect another device.
The Garmin range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.
The Garmin range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.
Technical Specification
| Electrical | |
| Rated Current | 4A |
| Rated Voltage | 60VDC |
| Mechanical | |
| Male Contact | Brass, gold plated |
| Female Contact | Phosphor bronze, gold plated |
| Contact Carrier | PBT, black |
| Contact Polarisation | Standard M12 -“A”- polarisation |
| Mating Thread | M12 |
| Screw Cap | Plastic |
| O-Ring Seal | Rubber, black |
| Housing | PVC, black |
| Weight | 47g |
| Approvals and Certifications | |
| NMEA 2000 Approved | |
| RoHS Compliant | |
| UL Certified (UL1277) | |
| Protection | IP67 (when mated) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
